LACO ORIGINAL OPERATING INSTRUCTIONS TITANTEST™
57
© 2018 LACO TECHNOLOGIES, INC. - [TitanTest itna01en1-07 BA.fm] - 1807
7. Warning and error
messages
Malfunctions are displayed by warnings and error messages.
Warnings indicate problems, but measurements generally remain possible.
In the case of error messages, measurements can no longer be made.
Warnings and error messages signal an alarm tone whose frequency switch-
es between 500Hz and 1200Hz every 400ms. In addition, a message is dis-
played. A warning or error message consists of a number and a descriptive
text.
If you press the "OK" button on the lower right in the window with the mes-
sage, the device is restarted.
The following tables display all the warning and error messages. It lists pos-
sible causes for the malfunction and instructions on how to eliminate these.
7.1 Warning messages
Warning messages warn of device modes that can impair the accuracy of
measurements. Operation of the device is not interrupted.
Table 29: Warning messages
No. Message Possible error sources
W69 TMP fault – - Untreated error message of the turbo molecular pump. More information about the error number can be
found in the instructions for the turbo molecular pump.
W101 Real-time clock was reset! Please enter
date and time.
– Battery on the MC 68 control board discharged / defective
– MC 68 changed
W102 Please recalibrate! – The automatic calibration prompt is activated and one of the following conditions is fulfilled:
– 30 minutes have expired since switching on the leak detector
– The pre-amplifier temperature has changed by more than 5 °C since the last calibration
– The mass setting has changed
–The filament was switched
– After the confirmation of this warning a warning triangle remains in the "Standby" menu, which signals the
existence of this interruption.
The warning triangle disappears as soon as this interruption has been corrected.
W103 Flow through capillary is too low! – Filter in filter tip clogged
– Sinter filter in filter tip soiled
– Capillary clogged by dirt
– Lower flow limit set incorrectly
– After the confirmation of this warning a warning triangle remains in the "Standby" menu, which signals the
existence of this interruption.
The warning triangle disappears as soon as this interruption has been corrected. "Standby".
W104 Capillary broken – Capillary broken or torn
– Upper flow limit set incorrectly
– After the confirmation of this warning a warning triangle remains in the "Standby" menu, which signals the
existence of this interruption.
The warning triangle disappears as soon as this interruption has been corrected.
W105 Global Reset – A global reset has been performed.
