LACO ORIGINAL OPERATING INSTRUCTIONS TITANTEST™
38
© 2018 LACO TECHNOLOGIES, INC. - [TitanTest itna01en1-07 BA.fm] - 1807
6.3.5 Volume & Beep
Minimum volume:
You can set the minimum volume. The volume may never be lower than the
minimum volume. You can set the volume in the measured value display.
The setting applies to the speaker in the device.
Setting range: 0 to 15
Beep Sound:
Activate or deactivate the beep sounds. The sounds signal a state change,
for example.
Select " Setup > Global settings > Volume & Beep".
6.3.6 Define the Auto Test settings**
Introduction The operating mode Auto Test is an automated test sequence with which
you can test the test objects using the vacuum method.
Depending on the configuration, you can test components pre-filled with
tracer gas or control a gas filling station in order to fill the test part with
tracer gas during the test sequence. In addition, you can test components
according to the spraying method.
The Auto Test sequence is subdivided into the following steps:
Evacuation of the vacuum chamber
Filling of the test object with tracer gas (if necessary) or spraying of test
part
Measurement of the leakage rate
Venting of the vacuum chamber
If the measured leakage rate exceeds the setpoint, the device will display
the message "FAIL" or "PASS" for leakage rates below the setpoint at the end
of the test sequence.
Affected areas In order to use the "Auto Test" function, make the following settings:
Set the setpoint (see Chapter 6.4.7: "Set the setpoint and alarm", page 47)
Set the "Maximum Evacuation Time" (see Chapter 6.4.4: "Define evacuation
time & vent", page 45)
Set the "Delay Timer"
Set the "Test Timer"
Set the "Background Limit"
** Feature not available in TITANTEST™ Maintenance model
Hearing damage from excessively loud signal tones
The volume of the signal tones may exceed 85 dB(A).
► Keep away from the device when setting high volumes.
► Wear ear protection when necessary.
