Please refer to the separate operating instructions for additional informa-
tion.
The wired remote control is connected to connection 2 (RC) (see Fig. 5,
page 19).
5.8 Fore pump exhaust line
If the TITANTEST™ is operated in poorly ventilated spaces, an exhaust gas line
is required.
The exhaust gas line is not included in the scope of delivery. It is the duty of
the owner to provide an exhaust gas line and to ensure the discharge of ex-
haust gases. Connect on 8 mm OD or 5/16" OD poly tube.
► Connect the exhaust gas line to exhaust port 5 (see Fig. 5, page 19).
5.9 Venting or chamber
In vacuum test modes, if the test object is vented with a gas – e.g. argon or
dry nitrogen – instead of with air, a gas source is connected to the device.
Connect the gas source to connection 4 (see Fig. 5, page 19).
The pressure at the venting connection may not exceed 0.1 bar.
5.10 Connecting to the power supply system
1. Check whether the supply voltage specified on the TITANTEST™ rating
plate matches the supply voltage available on site.
2. Connect the device to the electric power supply using the supplied
power cable.
Danger from exhaust gases and vapors
Exhaust gases and vapors from oil-sealed pumps may be harmful to health.
► When operating the device in poorly ventilated spaces, mount an ex-
haust gas line on the T
ITANTEST™.
Material damage due to incorrect supply voltage
An incorrect supply voltage may damage the device.
