► You can switch between the analog/digital display and the graphic dis-
play using the lower right button. This button alternately shows the ana-
log display symbol and the graphic display symbol.
For more information, see Chapter 6.2: "Operating the device", page 22.
6.6 Calling up information about the device
Various information about the state of the device can be called up. The in-
formation is shown on the display in the form of lists or graphs.
► Select " Setup > Information".
The menu allows you to access the following information:
–Settings
–System data
– Vacuum diagram
– Error list
– Calibration history
You can also locate the installed remote control by means of an audible
signal via " Setup > Information > Paging function".
Settings The current settings of the device are listed in this menu.
The settings cannot be changed here.
► Select " Setup > Information > Settings".
System data The menu lists the current system data. The information is subdivided
according to subject on the following pages:
–PUMPS
– MASS SPECTRO.
– TEMP.& PRESSURES
–MISC.
–SERIAL COMM.
– DIGITAL INPUTS
– DIGITAL OUTPUTS
► Select " Setup > Information > System data".
Vacuum diagram The graphic representation of the measurement system shows
– the current switching status of the valves
– the background value
– the backing pump pressure at the input of the backing pump (p1) and
at the test port (p2) measured by the gages
► Select " Setup > Information > Vacuum diagram".
Error list The error list shows the last 12 reported errors.
For each error, the data and time, the error message number, and part of a
comment are displayed. One of the error messages is always selected. You
can move the selection up or down using buttons next to the arrow sym-
