Fig. 3: Rear view
Mains plug a
The mains plug for switching the device on and off.
Power supply
b
Connection for power supply cable. The power supply is conducted via this
cable.
a Mains plug, covered by a label
b RoHS label
c Power supply, covered by a label
d Rating plate with information regarding supply
voltage, serial number and production date
e Connection strip
f Oil sight glass
g Exhaust line for M-Series with plug,
which must be removed before
switching on (pictured)
alternatively
Oil drain for P-Series (not pictured)
