LACO ORIGINAL OPERATING INSTRUCTIONS TITANTEST™
11
© 2018 LACO TECHNOLOGIES, INC. - [TitanTest itna01en1-07 BA.fm] - 1807
Exhaust port P-Series DN 25 ISO-KF
External backing vacuum connection DN 25 ISO-KF
Venting connection (N
2
) Sniffer line connection, for hose ø6/4 mm
Max. pressure on venting connection 1.1 bar
Ambient conditions
Te mp erature
Storage - 10 °C to 55 °C (14 °F to 131 °F)
Operation - 10 °C to 35 °C (14 °F to 95 °F)
Max. relative humidity up to 31 °C (88 °F) 80 %
Max. relative humidity from 31 °C (88 °F) to 35 °C (95 °F) linearly decreasing from 80 % to 50 %
Use only indoors
Max. altitude above sea level 2000 m a.s.l.
Noise level < 70 dB(A) (acc. to IEC standard)
Pollution degree II
(According to IEC 61010 / Part 1: "Usually, only non-
conducting contamination may occur. However,
temporary conductivity caused by condensation is
permissible at times.")
Electrical data
Supply voltages and frequencies
TTW102
TTW101
TTN150
230 V ± 10% / 50 Hz
120 V ± 10% / 60 Hz
100 V - 230 V ± 10% / 50/60 Hz
Protection class 1
Overvoltage category II
Current <10 A
Power consumption 720 VA (Wet Series)
150 VA (Dry Series)
Mains fuse 2 pieces, 10.0 AT, 250 V, ø5×20 mm
Physical data
Measuring
Operation modes Vacuum / Sniff / Auto Test
Ready for operation ≤3 minutes (pump run-up time)
Inlet pressure ≤18 mbar (up to 25 mbar allowed for short time)
Filament 2 (iridium yttriated)
Filter stages none
static
dynamic
Measuring rate 20 Hz
Display rate 3 Hz
Alarm
Acoustics / Volume adjustable
Setpoint / Pre-warning adjustable
Relay exit adjustable
Screen displays Leakage rate vs. time, analog / digital
Vacuum mode
Table 2: Technical data (Contin.)
