LACO ORIGINAL OPERATING INSTRUCTIONS TITANTEST™
62
© 2018 LACO TECHNOLOGIES, INC. - [TitanTest itna01en1-07 BA.fm] - 1807
E56 p1 > 10 mbar after run-up – The fore-vacuum pressure p1 after 5 min. in run up is > 10 mbar
–Fore pump defective
– Leaks in the vacuum system
– Valve V1 does not open
E60 TMP frequency too high (E001)! – Rated speed of 1,500 Hz exceeded by 5 %.
– Check connecting cable, restart leak detector
– TC 110 defective
E61 TMP power supply faulty (E002)! – Error detected in the power supply unit TC 110.
– Power supply unit defective (electronic drive unit TMP)
E62 TMP start-up time error (E006)! – Speed of the TMP is below the speed switching point < 1,200 Hz 15 min. after starting.
– Turbo pump bearing damage
– TC 110 defective
E63 TMP connection TC to pump faulty (E008)! – TMP connection between TC 110 and TMP defective
– Check proper assembly of TC 110 on TMP
– TC 110 defective
E64 TMP controller TC faulty (E015)! – TMP controller TC 110 detected as defective.
– Exchange TC 110
E65 TMP wrong resistor (E021)! – TMP controller detects wrong pump rated resistance
– Exchange TMP
E66 TMP motor control defective (E037)! – The control of the TMP motor is defective.
– Exchange TMP
– Exchange TC 110
E68 No communication with turbo pump. – No communication via the RS 485 between TC 110 and MC 68 control board
– Connection faulty or not plugged TC 110 – wiring board
– TC 110 defective
– MC 68 defective
E70 The offset voltage of the pre-amplifier is too
high. (>5 mV)
– The pre-amplifier is defective.
– Defective supply voltage pre-amplifier
E71 TMP temperature control faulty – Short circuit in the temperature sensor
E72 TMP temperature sensor faulty – Temperature sensor broken
Table 30: Error messages
No. Message Possible error sources
