Fig. 10-45 Mounting clip for FS 60 see the docu-
mentation for the desired device
Fig. 10-46 Mounting clip for FS60 (DLT7660)
Fig. 10-47 Flame sensor FFS 07
Marking Colour
BK black
BU blue
RD red
GN green
WH white
YE yellow
No. Description
1 Type plate
2 Grounding M4 (Pozidrive 2)
3 Incidence of light
4 Bend radius of the of the FM wire min. 25 mm
