Lantronix PremierWave XN User Manual

8: Line and Tunnel Settings
PremierWave® XN Intelligent Gateway User Guide 77
Table 8-1 Line Configuration Settings
Line Settings Description
Name Enter a name or short description for the line, if desired. By default, there is
no name specified. A name that contains white space must be quoted.
Interface Set the interface type for the Line. The default is RS232.
Choices are:
 RS232
 RS485 Full-Duplex
 RS485 Half-Duplex
Termination Select to Enable or Disable Line Termination. The default is Disable.
Note: This setting is only relevant for Interface type RS485 Half-Duplex.
State Select to enable or disable the operational state of the Line. The default is
Enabled.
Protocol Set the operational protocol for the Line. The default is Tunnel. Choices are:
 None
 Modbus RTU
 Modbus ASCII
 Tunnel = Serial-Network tunneling protocol.
Baud Rate Set the Baud Rate (speed) of the Line. The default is 9600.
Any set speed between 300 and 921600 may be selected: 300, 600, 1200,
2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400, 460800, 921600.
When selecting a Custom baud rate, you may manually enter any value
between 300 and 5000000.
Note: Custom baud rates are not supported when a line is configured for
Command Mode.
Parity Set the Parity of the Line. The default is None.
Data Bits Set the number of data bits for the Line. The default is 8.
Stop Bits Set the number of stop bits for the Line. The default is 1.
Flow Control Note: Set the flow control for the Line. The default is None.
Note: This field becomes available if RS232 or RS485 Full-Duplex is
selected under Interface above.
Xon Char Set Xon Char to be used when Flow Control is set to Software. Prefix decimal
with \ or prefix hexadecimal with 0x or prefix a single control character
<control>.
Note: This field becomes available for configuration when Software is
selected under Flow Control.
Xoff Char Set Xoff Char to be used when Flow Control is set to Software. Prefix decimal
with \ or prefix hexadecimal with 0x or prefix a single control character
<control>.
Note: This field becomes available for configuration when Software is
selected under Flow Control.
