23. Insert the upper insulator
(PLISR0042) so that the smaller gold
post is aligned with the upper insulator
hole.
The notch should approximately
face the back of the tip assembly.
The smaller boss should face
down.
24. Insert the upper plate so that the (2)
alignment holes are aligned with the
(2) gold posts.
25. Install the (3) M3 SHCS (PLSCR0042)
securing the top plate to the outer
body.
You will see (3) counterbores.
26. Insert the breakaway insulator
(PLISR0041) into the retainer nut.
27. Align the breakaway insulator and
retainer nut so that the breakaway
insulator alignment holes are in line
with the gold posts.
You will see (6) counterbores.
28. Install the (6) M3 SHCS (PLSCR0109)
securing the breakaway insulator to
the top plate.
29. Install the tip assembly on the head
according to Section 5.5.
30. Thread the tip retainer nut assembly
and gas jet tip onto the outer body.
