Press the [Parameter sets] button to display a list of available parameter sets.
If no data is available, the list will be empty.
When a data record is touched, it is displayed in a white font.
Pressing the [Display] button displays the selected parameter set. You
can read the data but you cannot modify it.
Pressing the [Load] button transfers the control parameters to the
thermostatic circulator automatically.
You can delete the selected parameter set by pressing the [Delete]
button and confirming a security prompt.
6.8.6 Editing internal control parameters
If you require the controller output limit, set it before adjusting the
control parameters. Ä Chapter 6.5 “Defining the actuating signal
limit” on page 89
The internal control in the device is active. Refer to Ä Chapter 6.6.1
“Activating external control, deactivating internal control” on page 89 for
information on reconfiguring the control.
The [Settings Tv/Td] menu item allows you to define whether the control
parameters [Tv] and [Td] are adapted manually or configured automatically.
If the automatic setting is enabled, both control parameters are marked with
the word "auto" and cannot be selected. In this case, [Tv] and [Td] are derived
with fixed factors of [Tn].
The slide switch in the [Settings Tv/Td] menu item allows you to define
whether the control parameters [Tv] and [Td] are adjusted manually or con-
figured automatically.
1.
Select the Control parameters Internal menu item in the Control
menu.
2. Touch a control parameter to select it.
An input window appears. A value can be entered within the limit
values displayed.
3. Change the value accordingly.
4. Press the [OK] button to return to the previous screen with the new
setting configured.
6.8.7 Editing external control parameters
If you require the controller output limit, set it before adjusting the control
parameters. Ä Chapter 6.5 “Defining the actuating signal limit” on page 89
The external control in the device is active. Refer to Ä Chapter 6.6.1
“Activating external control, deactivating internal control” on page 89 for
information on reconfiguring the control.
The [Settings Tve/Tde] menu item allows you to define whether the control
parameters [Tve], [Tde] and [Prop_E] are adapted manually or configured
automatically. If the automatic setting is enabled, all three control parame-
ters are marked with the word "auto" and cannot be selected. In this case,
[Tve] and [Tde] are derived with fixed factors of [Tne].
Adjusting control parameters manually or
automatically
Adjusting control parameters manually or
automatically
V6PRO bath thermostats and circulation thermostats102 / 156
