The response from the constant temperature equipment is always made
with a CRLF.
After each command is sent to the constant temperature equipment, it
is necessary to wait for the reply before sending another command. This
ensures that the sequencing of inquiries and answers is clear.
CR = Carriage Return (Hex: 0D); LF = Line Feed (Hex: 0A)
4.5.3 Error messages from the constant temperature equipment to the control station
Error messages are described in this list.
Error Description
ERR_2 Wrong entry (for example, buer overflow).
ERR_3 Wrong command
ERR_5 Syntax error in value
ERR_6 Impermissible value
ERR_8 Module or value not available.
ERR_30 All segments in the programmer are occupied.
ERR_31 Not possible to specify set point value, analog set point input set to ON.
ERR_33 An external temperature probe is missing.
ERR_34 Analog value not present.
ERR_35 Safety Mode cannot be started because the Safety Mode function has not been
activated.
ERR_36 Not possible to specify set point value, programmer is running or has been paused.
ERR_37 Impossible to start the programmer, analog set point value input is turned on.
ERR_38 Not possible to activate from Safety Mode.
4.6 Setting up the circulation thermostat
CAUTION!
Risk of heat transfer liquid escaping from incorrectly sealed
pump connections
Slipping hazard, loss of heat transfer liquid
Attach a stopper or pump link to the pump connections if
there is no external consuming unit connected.
4.7 Racks, platforms, rising platforms
This section is relevant for:
the Bath thermostat device category
V6 PRO bath thermostats and circulation thermostats 51 / 156
