Hose type Length in cm
Temperature range of
the hose in °C
Application area Catalog number
MK 150 150 -90 – 150
With foam insulation for the refrig-
eration sector, suitable for all
LAUDA heat transfer liquids
LZM 054
MK 200 200 -90 – 150
With foam insulation for the refrig-
eration sector, suitable for all
LAUDA heat transfer liquids
LZM 055
Pump short-circuit 18 -90 – 150
With foam insulation for the refrig-
eration sector, suitable for all
LAUDA heat transfer liquids
LZM 045
4.8.2 Connecting an external consuming unit
DANGER!
Risk of hot heat transfer liquid overflowing
Fire
 A connecting hose with a collecting vessel must be
attached to the overflow.
 The collecting vessel and connecting hose must be designed
to withstand the maximum temperature of the heat transfer
liquid.
 Avoid ignition sources in the vicinity of the collecting vessel.
WARNING!
Degradation of overflow or drain
Electric shock
 Overflow hose and drainage hose must each slope down-
ward separately all the way into a collecting vessel.
CAUTION!
Risk of external hydraulic circuit bursting from overpressure
Scalding, cold burns
 When laying the hoses, make sure they cannot kink.
 Use safety valves in the hydraulic circuit.
CAUTION!
Risk of heat transfer liquid escaping during operation due to
open consuming unit
Scalding, cold burns
 Always use hydraulically sealed consuming units.
V6PRO bath thermostats and circulation thermostats54 / 156
