Lauda P 10 User Manual

The slide switch in the [Settings Tve/Tde] menu item allows you to define
whether the three control parameters are adjusted manually or configured
automatically.
1.
Select the Control parameters  External menu item in the Control
menu.
2. Touch a control parameter to select it.

An input window appears. A value can be entered within the limit
values displayed.
3. Change the value accordingly.
4. Press the [OK] button to return to the previous screen with the new
setting configured.
6.8.8 Importing and exporting data
Data records and programs can be exported from the Command Touch
to a USB stick for subsequent import into another Command Touch. The
exported file is marked with a checkmark.
All the exported files are saved on the USB stick in the CommandFiles folder
and associated subfolders.
In this way, individual data records can be transferred to several thermostatic
circulators.
You can export the following files to the USB stick:
 [Programs]
 You can select stored temperature-time programs for export.
 [User database]
 This data record contains a list of all users authorized to operate the
Command Touch, together with their permissions.
 [Control parameters]
 Here, the temperature control parameters (Tn / Xp / Kpe / etc.)
currently set are exported to the USB stick.
 [Parameter sets]
 You can select the stored parameter sets for exporting.
 The set temperature T
set
, internal temperature T
int
and external tem-
perature T
ext
are saved in the [Log file] together with the relevant time
stamp. The log file can be exported in two dierent formats:
 As a PDF file for printing or
 As a text file for importing into EXCEL (in CSV format) or other
PC programs for further evaluation.
The data period of the record is limited to less than 24 hours.
You will require a USB stick. The export process is demonstrated using the
example of the log file.
1. Open the Home window.
2.
Select the Settings  Data export tiles.

The Export data menu appears.
Exporting data to a USB stick
V6 PRO bath thermostats and circulation thermostats 103 / 156
