Table 47: Cooling circulation thermostats
Heating output in kW
Power supply
Current consump-
tion setting*
RP 240 E RP 245 E RP 250 E RP 290 E
230 V; 50 Hz 13 2.5 2.5 --- ---
230 V; 50 Hz 15 2.5 2.5 --- ---
230 V; 50 Hz 16 2.5 2.5 2.5 2.5
208-220 V; 60 Hz 13 2.1 – 2.3 2.1 – 2.3 --- ---
208-220 V; 60 Hz 16 2.1 – 2.3 2.1 – 2.3 2.0 – 2.3 2.0 – 2.3
200 V; 50/60 Hz 16 1.9 1.9 1.9 1.9
120 V; 60 Hz 16 1.8 1.8 --- ---
100 V; 50/60 Hz 15 1.3 1.3 --- ---
100 V; 50/60 Hz 16 1.3 1.3 --- ---
11.5 Pump characteristics
Fig. 77: Pump characteristics of the circulation thermostats
V6 PRO bath thermostats and circulation thermostats 139 / 156
