Table 13: Rights
ID Function Unit Command
62 Keyboard master (equivalent to "KEY"): 0 = unlock / 1 = lock [–] OUT_MODE_00_X
64 Keyboard remote control unit (command): 0 = unlock / 1 = lock [–] OUT_MODE_03_X
Table 14: Status
ID Function Unit Command
74 Switch the device on/o (standby) [–] START/STOP
Note the following instructions:
" " (blank space) can also be used for "_".
Response from thermostat will be "OK" or, if there is an error, "ERR_X".
RS 485 interface for example "A015_OK" or if there is an error
"A015_ERR_X".
The command from the control station must be made with a CR, CRLF
or LFCR.
The response from the constant temperature equipment is always made
with a CRLF.
After each command is sent to the constant temperature equipment, it
is necessary to wait for the reply before sending another command. This
ensures that the sequencing of inquiries and answers is clear.
CR = Carriage Return (Hex: 0D); LF = Line Feed (Hex: 0A)
-XXXX.XX -XXXX.X -XXXX. -XXXX XXXX.XX XXXX.X XXXX. XXXX
-XXX.XX -XXX.X -XXX. -XXX XXX.XX XXX.X XXX. XXX
-XX.XX -XX.X -XX. -XX XX.XX XX.X XX. XX
-X.XX -X.X -X. -X X.XX X.X X. X
-.XX -.X .XX .X
4.5.2 Read commands of the interface
A read error is a query for current data sent to the constant temperature
equipment by the control station.
Table 15: Temperature
ID Function Unit, resolu-
tion
Command
2 Temperature set point [°C] IN_SP_00
3 Bath temperature (outflow temperature) [°C], 0.01°C IN_PV_00
4 Bath temperature (outflow temperature) [°C],
0.001°C
IN_PV_10
Acceptable data formats
Valid for the Ethernet interface and for the
RS 232/485 interface module
V6PRO bath thermostats and circulation thermostats46 / 156
