ID Function Unit, resolu-
tion
Command
5 Query of the controlled temperature (internal/external Pt/external analog/
external serial)
[°C] IN_PV_01
7 External temperature T
E
(Pt) [°C] IN_PV_03
8 External temperature T
E
(analog input) [°C] IN_PV_04
14 External temperature T
E
(Pt) [°C],
0.001°C
IN_PV_13
25 Overtemperature turn o point T_Max [°C] IN_SP_03
27 Limitation of outflow temperature TiH (upper limit) [°C] IN_SP_04
29 Limitation of outflow temperature TiH (lower limit) [°C] IN_SP_05
33 Set temperature T
set
in Safety Mode (safe set point in case of communica-
tion interruption).
[°C] IN_SP_07
Table 16: Pump
ID Function Unit Command
12 Flow rate
Flow controller must be connected
[l/min] IN_PV_07
18 Pump power stage [–] IN_SP_01
Table 17: Fill level
ID Function Unit Command
9 Bath level (fill level) [–] IN_PV_05
Table 18: Actuating signal
ID Function Unit Command
11 Resolution of controller actuating signal in per mill [0.1 %]
– negative value à device is cooling
– positive value à device is heating
[‰]
IN_PV_06
V6 PRO bath thermostats and circulation thermostats 47 / 156
