Notes
 Commercially available WLAN routers can be used for the connections
displayed in Fig. 16 and Fig. 17. The routers must have the necessary
connection function and meet the requirements in the relevant country
in which they are operated. However LAUDA recommends using an
industrial WLAN router for the configuration illustrated in Fig. 16.
4.4.2 Configuring the Ethernet interface
Data Value Unit
Ethernet - standard 10/100 MBit
A glossary with all the relevant explanations appears at the end of the
document.
PC control
 The PC control menu item enables the control for a PC or control
station. You can activate this function if you wish to control and monitor
the thermostat from a control station.
Before the constant temperature equipment and control station can be
operated together in a local network (LAN), the Ethernet interface must be
configured.
The Ethernet interface can be configured in two dierent ways:
Automatically
obtain LAN con-
figuration
- In order for this to work, a DHCP server must be
present in the local network (LAN). If communication
is direct, the control station must support the auto IP
standard.
Manually con-
figure LAN con-
figuration
- Manual configuration must be performed if a DHCP
server is not available, auto IP standard is not supported
or you wish to use the Ethernet interface with fixed IP
addresses.
1. Switch on the constant temperature equipment.
2. Open the Home window in the Command Touch unit.
3.
Touch the Settings  Basic settings  Ethernet configuration tile.

The Ethernet configuration submenu opens.
4. DHCP client: Set the slide switch to [O].

Manual input for the IP address
, subnet mask and standard
gateway is active.
5. Enter the numerical values for the IP address and subnet mask , for
example 120.0.0.13. The numerical values are entered byte by byte.
From left to right, from byte 4 to byte 1. Press [OK] to confirm each
byte.
6. Once you have entered the numerical values for the [IP address] and
[subnet mask], press the [Apply] button.
7. Enter the numerical values for the [standard gateway]. The numerical
values are entered byte by byte. From left to right, from byte 4 to
byte 1. Press [OK] to confirm each byte.
Technical data of the Ethernet interface
Manually configure LAN configuration
V6PRO bath thermostats and circulation thermostats38 / 156
