Table 9: Cooling
ID Function Unit Command
23 Cooling mode: 0 = O / 1 = On / 2 = Automatic [–] OUT_SP_02_[Value]
Table 10: Safety
ID Function Unit Command
34 Timeout communication via interface (1 - 99 seconds; 0 = O) [s] OUT_SP_08_[Value]
72 Activate Safety Mode = 1
Safe operating statuses of the device in the event of a fault are
defined in Safety Mode. These operating statuses must be entered
by the user beforehand.
[–] OUT_MODE_06_1
Table 11: Control parameters
ID Function Unit Command
38 Control parameter Xp [–] OUT_PAR_00_XX.X
40 Control parameter Tn (5– 180 s; 181 = O) [s] OUT_PAR_01_XXX
42 Control parameter Tv [s] OUT_PAR_02_XXX
44 Control parameter Td [s] OUT_PAR_03_XX.X
46 Control parameter KpE [–] OUT_PAR_04_XX.XX
48 Control parameter TnE (0– 9000 s; 9001 = O) [s] OUT_PAR_05_XXXX
50 Control parameter TvE (5 = O) [s] OUT_PAR_06_XXXX
52 Control parameter TdE [s] OUT_PAR_07_XXXX.X
54 Correction limitation [K] OUT_PAR_09_XXX.X
56 Control parameter XpF [–] OUT_PAR_10_XX.X
60 Control parameter Prop_E [K] OUT_PAR_15_XXX
Table 12: Control
ID Function Unit Command
58 Set point oset [K] OUT_PAR_14_XXX.X
66 Control in control variable X: 0 = internal / 1 = external Pt / 2 =
external analog / 3 = external serial / 5 = external Ethernet / 6 =
external EtherCAT / 7 = external Pt second (only on Integral)
[–] OUT_MODE_01_X
68 Oset source X for set point: 0 = normal / 1 = external Pt / 2 =
external analog / 3 = external serial / 5 = external Ethernet / 6 =
external EtherCAT / 7 = external Pt second
[–] OUT_MODE_04_X
Comment (ID 66 and 68): If X=3, the commands ID 66 and ID 68 cannot be executed in some constant temperature
control devices until an external temperature specification has been received (via the command ID 15). Also notice that
the command OUT_PV_05_XXX.XX must be cyclically transmitted by the selected interface.
V6 PRO bath thermostats and circulation thermostats 45 / 156
