Please also note the following:
When laying the water cooling and heat transfer liquid hoses, make sure
that the hoses cannot be kinked or crushed.
Hose type
Clear Ø in
mm
Outer diam-
eter in mm
Temperature
range of the
hose in °C
Application area
Catalog
number
EPDM hose, uninsu-
lated
9 13 10 – 90
for all LAUDA heat transfer liquids
except mineral oils
RKJ 111
EPDM hose, uninsu-
lated
12 16 10 – 90
for all LAUDA heat transfer liquids
except mineral oils
RKJ 112
EPDM hose, insulated 12 35 -35 – 90
for all LAUDA heat transfer liquids
except mineral oils
LZS 021
Silicone tube, uninsu-
lated
11 15 10 – 100 Water, glycol/water mixture RKJ 059
Silicone tube, insu-
lated
11 33 -60 – 100 Water, glycol/water mixture LZS 007
Heat transfer liquids approved for the device can be found in
Ä Chapter 5.1 “LAUDA heat transfer liquids” on page 59.
The following approved metal hoses with M16 x 1 cap nuts are manufactured
from stainless steel. The clear opening measures 10 mm.
Hose type Length in cm
Temperature range of
the hose in °C
Application area Catalog number
MC 50 50 10 – 400
With single insulation, suitable for
all LAUDA heat transfer liquids
LZM 040
MC 100 100 10 – 400
With single insulation, suitable for
all LAUDA heat transfer liquids
LZM 041
MC 150 150 10 – 400
With single insulation, suitable for
all LAUDA heat transfer liquids
LZM 042
MC 200 200 10 – 400
With single insulation, suitable for
all LAUDA heat transfer liquids
LZM 043
Pump short-circuit 18 10 – 400
With single insulation, suitable for
all LAUDA heat transfer liquids
LZM 044
MK 50 50 -90 – 150
With foam insulation for the refrig-
eration sector, suitable for all
LAUDA heat transfer liquids
LZM 052
MK 100 100 -90 – 150
With foam insulation for the refrig-
eration sector, suitable for all
LAUDA heat transfer liquids
LZM 053
Approved elastomer hoses
Approved metal hoses
V6 PRO bath thermostats and circulation thermostats 53 / 156
