Speciļ¬cation Description
SCCR: Indicates the short-circuit current according to NEC 110-10
or UL508A which the components and assemblies used in the
machine can withstand
Compressor FLA I: Current consumption of Compressor I under full load
Compressor HP I: Power of Compressor I in horse power
Compressor FLA II: Current consumption of Compressor II under full load
Compressor HP II: Power of Compressor II in horse power
Pump FLA I: Current consumption of Pump I under full load
Pump HP I: Power of Pump I in horse power
Pump FLA II: Current consumption of Pump II under full load
Pump HP II: Power of Pump II in horse power
Refrigeration fan FLA: Current consumption of the fan under full load
Refrigeration fan HP: Power of the fan in horse power
Values (HP and FLA) for the compressor, pump and refrigeration
fan are only provided on the rating label for components with a per-
formance class over 0.75 HP. For components with a performance
class under 0.75 HP, no values (HP and FLA) are provided on the
rating label.
Fig. 12: Rating label for a heating thermo-
stat (example)
V6PRO bath thermostats and circulation thermostats30 / 156
