LAUNCH X-431 PAD III User Manual
6
5 VOLUME +/- Key To adjust the volume.
6 Reset Switch
7 USB1 Port Only reserved for Micro USB cable.
8 HDMI Port
To connect an external projector or monitor with
HDMI interface.
9 Memory Card Slot To insert a memory card for memory extension.
10 Earphone Jack
11
POWER/Screen
Lock Key
In Off mode, press it for 3 seconds to turn the
handset on.
In On mode:
 Press it to activate the LCD if the LCD is off.
 Press it to turn off the LCD if the LCD lights up.
 Press it for 3 seconds to turn it off.
 Press it for 8 seconds to perform forced
shutdown.
12
Ambient Light
Sensor
13 Charging LED
14 Touch Screen
15 Front Camera
