LAUNCH X-431 PAD III User Manual
9
and flashes. Otherwise, it will not illuminate.
 Power: It illuminates solid red when the module is powered on.
 Bluetooth: Blue indicates the module is working in Bluetooth mode.
 USB: It lights up when the module is connected to the diagnostic tool
via USB cable.
 Wi-Fi: It lights up when the module works as a Wi-Fi hotspot or
wireless adaptor.
4
USB port: For connecting it to the handset via USB cable to perform
vehicle diagnosis.
2.3 Package List
Common accessories for each X-431 PAD III are same, but for different
destinations, the accessories of X-431 PAD III may vary. For detailed accessory
items, please consult from the local agency or check the packing list supplied
with X-431 PAD III together.
No. Item Description Qt.
1 X-431 PAD III tablet
For analyzing the vehicle data and indicating
the test results.
1
2 VCI connector
For connecting to vehicle’s OBD II DLC to
access vehicle’s live data.
1
3
OBD II extension
cable
For connecting the VCI connector for
extension purpose.
1
4 OBD I adaptor
For connecting the non-16pin connector to
the VCI connector.
1
5
Cigarette lighter
cable
Optional. To supply power to the non-16pin
connector through connection to the
vehicle’s cigarette lighter receptacle.
1
6
Battery clamps
cable
Optional. To supply power to the non-16pin
connector through connection to the
vehicle’s battery.
1
