LAUNCH X-431 PAD III User Manual
5
2.1 X-431 PAD III Tablet
Fig. 2-3 X-431 PAD III tablet
1
Adjustable
kickstand
Flip out it to any angle and work comfortable at
your desk, or hang it on automotive part.
2 USB2 Port
To connect the USB devices or add-on USB
modules (Scopebox, Sensorbox or Batterybox)
while extending X-431 PAD III function.
3 Ethernet port
To connect the Ethernet cable for wired
network.
4 DC IN Port To connect the included power adaptor.
