UserManualforELD2Servo
Introduction
Thanks for purchasing Leadshine ELD2-series low-voltage AC servo drivers, this instruction
manual provides knowledge and attention for using this driver.
Contacttech@leadshine.comformoretechnicalser vice.

Incorrectoperationmaycauseunexpectedaccident,pleasereadthismanualcarefullybefore
usingproduct.
 We reserve the right to modify equipment and documentation without prior notice.
 We won’t undertake any responsibility with customer’s any modification of product, and the warranty of
product will be cancel at the same time.

Beattentiontothefollowingwarningsymbol:
Warningindicatesthattheerroroperationcouldresultinlossoflifeorseriousinjury.
Cautionindicatesthattheerroroperationcouldresultinoperatorinjured,alsomakeequipment
damaged.
Attent ion   indicatesthattheerrorusemaydamageproductandequipment.

Safetyprecautions
Warning
 The design and manufacture of product doesn’t use in mechanic and system which have a threat to
operator.
 The safety protection must be provided in design and manufacture when using this product to prevent
incorrect operation or abnormal accident.

Acceptance
Caution
 The product which is damaged or have fault is forbidden to use.

Transportation
Caution
 The storage and transportation must be in normal condition.
 Don’t stack too high, prevent falling.
 The product should be packaged properly in transportation,
 Don’t hold the product by the cable, motor shaft or encoder while transporting it.
 The product can’t undertake external force and shock.
Installation
Caution
ServoDriverandServoMotor:
 Don’t install them on inflammable substance or near it to preventing fire hazard.
 Avoid vibration, prohibit direct impact.
 Don’t install the product while the product is damaged or incomplete.
