86 X75HD Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 6: Specifications
Video Specifications
Input
Table 6-1. HD-SDI Video Input Specifications
Item Specification
Standard SMPTE292M
Connector BNC (IEC169-8)
Impedance 75
W
Return loss >18 dB, typical, from 5 MHz to 1485 MHz
Equalization Adaptive cable equalization for up to—
• 388 ft (100 m), typical, of Belden 8281
co-axial cable
or
• 492 ft (150 m), typical, of Belden
1694A co-axial cable
Table 6-2. HDTV Fiber Video Input
Item Specification
Standard SMPTE 292M, Mode B Operation
Number of inputs 1
Connector Single mode fiber, SC connector standard
(FC or ST type optional)
Input wavelength 1200 to 1600 nm
Max. input power 0 dBm, typical
Sensitivity Better than -20 dBm
