76 X75HD Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 5: Initial Configuration
Configuring for HTTP Control
(via Web Browser)
Once the networking parameters of the X75HD have been configured
appropriately, and it is connected to the Ethernet network, the built-in
Web server allows a standard Web browser to control the X75HD unit.
Before controlling your unit in this way, note the following system and
browser requirements:
• The X75HD supports Web browsers that are compatible with
HTML 4.0 (and later).
• Although most standard Web browsers can be used with the
X75HD for HTTP control, the following browsers have been tested
and approved by Leitch: Microsoft® Internet Explorer 6.0,
Netscape® Navigator™ 7.2, and Mozilla® Firefox™ 1.0.
Procedure
To select a unit for control, follow these steps:
1. Ensure all required connections and network settings have been
made locally on your X75HD unit(s).
2. Open a supported Web browser, and then type the IP address of the
unit you wish to control into the Address, Location, or URL field
of your Web browser (the name of the field depends on the Web
browser you are using). For example, type the following to control
an X75HD unit with this IP address:
http://192.168.100.250
The Web browser then displays the Home page of the X75HD
Control interface (Web server).
See “Chapter 9: Controlling the X75HD via Web Server Software” for
more information.
Note
Web browser control is only
available for X75HD units, and
not for RCP-X75 panels.
