X75HD Installation and Operation Manual 17
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Options
Table 1-2 describes the various options available for X75HD systems.
Some can be installed in the factory at the time of purchase, while other
options and upgrades can be ordered and installed at a later time by you.
For further cable and cable pinout information, see “Appendix A:
Cables and Pinouts”.
Table 1-2. X75HD System Options and Cables
Product Code Description Major Features
System Options
AS-X75HD Optional sixteen channel digital
audio synchronizer submodule for
separate/embedded audio
Mounts inside any X75HD system, and
includes the following:
• Analog, AES/EBU, and embedded
SD-SDI audio I/O
• Sixteen-channel processing
• Audio analog-to-digital conversion
• Audio digital-to-analog conversion
• Audio embedding
• Audio de-embedding
• Audio synchronizing
• Audio delay insertion
• Audio processing amplification
Comes with CAB-X75HD-COAX and
CAB-X75-COAX breakout cables
FCFIBER-X75HD Optional FC type fiber connectors FC type fiber connectors (factory installed)
STFIBER-X75HD Optional ST type fiber connectors ST type fiber connectors (factory installed)
A3D-X75 Optional high performance
3D-adaptive decoder, component
Betacam, S-video input
• Input submodule
• Field upgradable or factory installed
RCP-X75 Optional remote control panel Remote panel, field-upgradable
X75PS Optional power supply kit Field upgradeable
