Chapter 1: Introduction
Cable Options
CAB-X75MULTI Optional accessory cable set for
multi I/O connector
Provides the following connections:
1 ft (30 cm) multi I/O breakout cable with the
following connector types:
• DB26(M)—6 x BNC(F)
•1 x XLR(F)
• 1 x MiniDin4(F)
•4 x RCA(F)
CAB-X75-DVI Optional cable for DVI output
connector
DVI-D to DVI-D (digital-single link) cable
CAB-X75-COMBO Optional cable for systems that
require both XLR and BNC
connectors
Provides the following connections:
1 ft (30 cm) breakout cable with the
following connector types:
• DB26(M)—5 x BNC(F)
•3 x XLR(F)
•2 x XLR(M)
Table 1-2. X75HD System Options and Cables (Continued)
Product Code Description Major Features
• SDTV audio
delay
• HDTV audio
delay
• GPI1 out
• GPI2 out
•GPI1 in
•GPI2 in
• Sync comp
out
•Blue out
• Green out
• Red out
•Y/C out
• Time code in
XLR
• DARS in
•AES1 in
•AES2 in
•AES1 out
•AES2 out
BNC
•DARS in
•AES1 in
•AES2 in
• AES1 out
• AES2 out
