CAB-X75HD-COMBO Optional cable for systems that
require both XLR and BNC
connectors
Provides the following connections:
1 ft (30 cm) breakout cable with the
following connector types:
• DB26(M)—6 x BNC(F)
•3 x XLR(F)
•3 x XLR(M)
CAB-X75-XLR Optional cable for systems that
require XLR connectors
Provides the following connections:
1 ft (30 cm) breakout cable with the
following connector types:
• DB26(M)—3 x XLR(F)
•2 x XLR(M)
CAB-X75HD-XLR Optional cable for systems that
require XLR connectors
Provides the following connections:
1 ft (30 cm) breakout cable with the
following connector types:
• DB26(M)—3 x XLR(F)
•2 x XLR(M)
Table 1-2. X75HD System Options and Cables (Continued)
Product Code Description Major Features
XLR
•AES3 in
•AES4 in
•AES5 in
•AES3 out
•AES4 out
•AES5 out
BNC
•AES3 in
•AES4 in
•AES5 in
• AES3 out
• AES4 out
• AES5 out
•AES1 out
•AES2 out
•DARS in
•AES1 in
•AES2 in
•AES3 out
•AES4 out
•AES5 out
•AES3 in
•AES4 in
•AES5 in
