Chapter 4: System Installation and Connections
Checking the Packing List
Before unpacking your product, read the “Unpacking/Shipping
Information” on page v.
Standard Items
The following items are included with every X75HD system:
• One X75HD High-Definition Digital Processing Synchronizer
• One AC power cable (773-254 or 773-505)
• Two rear support brackets (741-983A) and corresponding hardware
• Two cable relief support brackets (164-000306-00) and one
corresponding cable relief bar (164-000305-00)
These items are only included with X75HD-AV/X75HD-LCAV
systems:
• Two 2x7 analog audio terminal blocks (134-000228-00); this item
may be pre-installed on your unit
• HDTV audio module
(AS-X75HD), with CAB-X75HD-COAX and
CAB-X75-COAX breakout cables
Optional Items
You may have additional items included in your shipment if you have
ordered any of the available options or upgrades. Some options may
include the following:
• CAB-X75MULTI breakout cable
• CAB-X75DVI DVI-D digital video cable
• CAB-X75-COMBO audio breakout cable
• CAB-X75HD-COMBO audio breakout cable
• CAB-X75-XLR audio breakout cable
• CAB-X75HD-XLR audio breakout cable
• A3D-X75 high performance 3D-adaptive decoder, component
Betacam, S-video input
• RCP-X75 remote control panel
• X75PS power supply kit for optional, redundant power supply
(typically factory installed, although can be field-upgraded)
