6 X75HD Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 1: Introduction
Main Features
All X75HD features and functions can be accessed from an installed
front local control panel, an RCP-X75™ remote control panel, or a
supported Web browser. Along with the applications described on
“Chapter 2: X75HD Applications”, the X75HD includes the following
features:
General Functionality
• Frame syncs for analog, SDTV and HDTV
• Up-converter, down-converter, cross-converter, and aspect ratio
converter
• Analog-to-digital converter
• Digital-to-analog converter
• Optional SDTV and HDTV logo generator
• Proc amps for analog, SDTV and HDTV
• 16 channels of internal audio processing (gain, invert, swap,
sync/delay, sum)
• Embedding and de-embedding for SD-SDI and HD-SDI
• Audio (and embedded) test generator
• Built-in Web server with thumbnail monitoring
Input/Outputs
• Auto-detected inputs
• Two SD-SDI and two HD-SDI inputs
• Color black, tri-level sync and DARS reference inputs
• Optional NTSC/PAL-M/PAL-B/SECAM input with CAV and
S-video inputs
• Ability to provide all outputs (composite, component, SD-SDI,
HD-SDI, HDTV fiber, DVI-D, S-video)
• SC and optional FC and ST fiber interface for HDTV
• Five AES inputs and outputs, 75/110W
• Four analog audio inputs and outputs
• GPI input and output
