4 X75HD Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 1: Introduction
General Description
The X75HD offers unparalleled I/O flexibility. Up to nine video inputs
and ten video output formats are provided, dependant on the selected
options:
• One HDTV optical fiber serial component digital video input and
output
• Two HDTV serial component digital video (HD-SDI) inputs and
one output
• Two SD-SDI serial component digital video inputs and outputs
• Streaming video output over IP (audio optional)
• Component analog video (Betacam®) input and output (input
optional)
• S-video (S-VHS/Hi8) input and output (input optional)
• NTSC/PAL-M/PAL-B/SECAM composite video input and output
(input optional)
• RGB-S output
• DV (IEEE-1394) input or output with transport control (optional)
• DVI-D output
See “Chapter 2: X75HD Applications” for a description of the various
X7HD applications that are available.
Inputs
Inputs are auto-detected with user selectable SMART alarms.Two input
modes for automatic detection or selection allow for critical program
path processing for ingest, bridges between routers/tape
transports/servers, mobile broadcast, and edit suites.
Video Processing
Processing for video includes level/color control, 3D-adaptive color
decoding, frame synchronization and time base correction for
non-synchronous signals, analog-to-digital and digital-to-analog video
conversion for hybrid facilities, up- and down-conversion with aspect
ratio conversion for hybrid standard definition and high-definition
facilities, and high-definition cross-conversion for broadcast and
production facilities with multiple high-definition format requirements.
Note
See “Product Packages” on
page 15 for more specific
information on what each
X75HD system package
provides.
