Chapter 9: Controlling the X75HD via Web Server Software
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Figure 9-3. Sequence of Pages that Result During Navigation (Example)
1. Main menu page
Click Routing Setup to open the
corresponding menu page
2. Routing Setup menu page
Click Video In Precedence to open the
corresponding menu page
3. Video In Precedence
menu page
Click a parameter name from
the table (in this example, SD1
In) to open the corresponding
parameter configuration page
4. SD1 In parameter configuration page
Change the parameter (currently set to
Normal); see “Setting a Selected Value”
on page 120 for more information
To Next Page
