X75HD Installation and Operation Manual 21
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Figure 1-9. Typical Configuration, Control, and Monitoring Methods
Remote control hardware panel
RCP-x75
Remote PC-based software control and monitoring options
Existing Leitch products
DPS-575
SNMP
(reserved for future use)
Web browser
Third-party control
software
(reserved for future use)
HP
Openview
TM
Netscape
Navigator/
MS IE
CCS EP
Pilot/
Navigator
CCS application
(reserved for future use)
x75HD high-definition digital processing synchronizer
3rd party hub or switch
