58 X75HD Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 4: System Installation and Connections
S-Video (Y/C) Output
This four-pin mini-DIN connector on the Multi I/O breakout cable
provides processed, synchronized/time base-corrected S-video (Y/C)
output.
RGB (Blue, Green, Red) Video Output
These four BNC connectors on the Multi I/O breakout cable,
comprising auxiliary Red, Green, Blue, and Sync, provide processed,
synchronized/time base-corrected RGB(S) (RGB with auxiliary sync)
video output. All three RGB channels’ sync signals can be
independently turned On or Off. If RGB without auxiliary sync is
sufficient, the Sync/Composite connection can be reassigned as an
auxiliary composite output.
Synchronized Composite Output
The Sync Comp connection on the Multi I/O breakout cable, normally
used for sync in RGB(s) (RGB with auxiliary sync) video output, can be
reassigned to provide an auxiliary composite video output with the Aux
Sync/Comp option in the Video Setup menu.
GPI1 and GPI 2 Input/Output
Two RCA-jack GPI inputs are provided on the Multi I/O breakout
cable. These allow a GPI-based external controller to trigger functions
of the unit. The function triggered by each GPI input is configured in
the System Config menu, under the Setup submenu.
Two RCA-jack GPI outputs are provided on the Multi I/O breakout
cable. These outputs can be configured as a GPI output to trigger
external devices. The functionality of this output is configured with the
GPO Output parameter, found within the System Config menu, under
the Setup submenu.
Time Code Input
This connector is reserved for future use.
