vNICs for iSCSI on Emulex Virtual Fabric Adapter

TheENOSvNICfeatureworkswithstandardnetworkapplicationslikeiSCSIas

previouslydescribed.However,theEmulexVirtualFabricAdapterforLenovo

FlexSystemexpectsiSCSItraffictooccuronlyonasinglevNICpipe.Whenusing

theEmulexAdapter2,onlyvNICpipe2mayparticipateiniSCSI.

Toconfigure

theswitchforthissolution,iSCSItrafficshouldbeplacedinitsown

vNICgroup,comprisedoftheexternaluplinkportleadingtotheiSCSItarget,and

therelated<port>.2vNICpipesconnectedtotheparticipatingservers.For

example:

1. EnablethevNICfeatureontheswitch.

2. Configurethevirtualpipes

fortheiSCSIvNICsattachedtoeachinternalport:

Note: vNICsarenotsupportedsimultaneouslyonthesameswitchportsas

VMready.

3. AddportsandvirtualpipestoavNICgroup.

CN 4093 # vnic enable

CN 4093(config)# vnic port INTA1 index 2 (SelectvNIC2ontheserverport)

CN 4093(vnic_config)# enable (EnablethevNICpipe)

CN 4093(vnic_config)# exit

CN 4093(config)# vnic port INTA2 index 2(SelectvNIC2ontheserverport)

CN 4093(vnic_config)# enable (EnablethevNICpipe)

CN 4093(vnic_config)# exit

CN 4093(config)# vnic port INTA3 index 2(SelectvNIC2ontheserverport)

CN 4093(vnic_config)# enable (EnablethevNICpipe)

CN 4093(vnic_config)# exit

CN 4093(config)# vnic vnicgroup 1 (SelectvNICgroup)

CN 4093(vnic-group-config)# vlan 1000 (SpecifytheVLAN)

CN 4093(vnic-group-config)# member INTA1.2(AddiSCSIvNICpipestothegroup)

CN 4093(vnic-group-config)# member INTA2.2

CN 4093(vnic-group-config)# member INTA3.2

CN 4093(vnic-group-config)# port EXT1 (Addtheuplinkporttothegroup)

CN 4093(vnic-group-config)# enable (EnablethevNICgroup)

CN 4093(vnic-group-config)# exit
