Figure 59. TwoLAGs,oneFailoverTrigger

Setting the Failover Limit

Thefailoverlimitletsyouspecifytheminimumnumberofoperationallinks

requiredwithineachtriggerbeforethetriggerinitiatesafailoverevent. For

example,ifthelimitistwo,afailovereventoccurswhenthenumberofoperational

linksinthetriggeristwoorfewer.Whenyousetthe

limittozero,theswitch

triggersafailovereventonlywhennolinksinthetriggerareoperational.

Trigger 1

VLAN 1:

VLAN 2:

VLAN Monitor = Off

Routing Switch

Enterprise

Internet

Server 1

Server 3

Server 2

Server 4

Switch 1

Switch 2
