532 CN4093 Application Guide for N/OS 8.4
Task 1: Configure CN4093 1
1. Configureclientandserverinterfaces.
2. Configurethedefaultgateways.EachdefaultgatewaypointstoaLayer3router.
3. TurnonVR RPandconfiguretwoVirtualInterfaceRouters.
4. Enabletrackingonports.SetthepriorityofVirtualRouter1to101,sothatit
becomestheMaster.
CN 4093(config)# interface ip 1
CN 4093(config-ip-if)# ip address 192.168.1.100 255.255.255.0
CN 4093(config-ip-if)# vlan 10
CN 4093(config-ip-if)# enable
CN 4093(config-ip-if)# exit
CN 4093(config)# interface ip 2
CN 4093(config-ip-if)# ip address 192.168.2.101 255.255.255.0
CN 4093(config-ip-if)# vlan 20
CN 4093(config-ip-if)# enable
CN 4093(config-ip-if)# exit
CN 4093(config)# interface ip 3
CN 4093(config-ip-if)# ip address 10.0.1.100 255.255.255.0
CN 4093(config-ip-if)# enable
CN 4093(config-ip-if)# exit
CN 4093(config)# interface ip 4
CN 4093(config-ip-if)# ip address 10.0.2.101 255.255.255.0
CN 4093(config-ip-if)# enable
CN 4093(config-ip-if)# exit
CN 4093(config)# ip gateway 1 address 192.168.1.1
CN 4093(config)# ip gateway 1 enable
CN 4093(config)# ip gateway 2 address 192.168.2.1
CN 4093(config)# ip gateway 2 enable
CN 4093(config)# router vrrp
CN 4093(config-vrrp)# enable
CN 4093(config-vrrp)# virtual-router 1 virtual-router-id 1
CN 4093(config-vrrp)# virtual-router 1 interface 1
CN 4093(config-vrrp)# virtual-router 1 address 192.168.1.200
CN 4093(config-vrrp)# virtual-router 1 enable
CN 4093(config-vrrp)# virtual-router 2 virtual-router-id 2
CN 4093(config-vrrp)# virtual-router 2 interface 2
CN 4093(config-vrrp)# virtual-router 2 address 192.168.2.200
CN 4093(config-vrrp)# virtual-router 2 enable
CN 4093(config-vrrp)# virtual-router 1 track ports
CN 4093(config-vrrp)# virtual-router 1 priority 101
CN 4093(config-vrrp)# virtual-router 2 track ports
CN 4093(config-vrrp)# exit
