© Copyright Lenovo 2017 Chapter 26: Routing Information Protocol 433
RIP Configuration Example
Note: AninterfaceRIPdisabledusesallthedefaultvaluesoftheRIP,nomatter
howtheRIPparametersareconfiguredforthatinterface.RIPsendsoutRIP
regularupdatestoincludeanUPinterface,butnotaDOWNinterface.
1. AddVLANsforroutinginterfaces.
2. AddIPinterfaceswithIPv4addresses
toVLANs.
3. TurnonRIPgloballyandenableRIPforeachinterface.
CN 4093(config)# vlan 2
CN 4093(config-vlan)# exit
CN 4093(config)# interface port 2
CN 4093(config-if)# switchport mode trunk
CN 4093(config-if)# switchport trunk allowed vlan add 2
CN 4093(config-if)# exit
Port 2 is an UNTAGGED port and its current PVID is 1.
Confirm changing PVID from 1 to 2 [y/n]: y
CN 4093(config)# vlan 3
CN 4093(config-vlan)# exit
CN 4093(config)# interface port 3
CN 4093(config-if)# switchport mode trunk
CN 4093(config-if)# switchport trunk allowed vlan add 3
CN 4093(config-if)# exit
Port 3 is an UNTAGGED port and its current PVID is 1.
Confirm changing PVID from 1 to 3 [y/n]: y
CN 4093(config)# interface ip 2
CN 4093(config-ip-if)# enable
CN 4093(config-ip-if)# ip address 102.1.1.1
CN 4093(config-ip-if)# vlan 2
CN 4093(config-ip-if)# exit
CN 4093(config)# interface ip 3
CN 4093(config-ip-if)# enable
CN 4093(config-ip-if)# ip address 103.1.1.1
CN 4093(config-ip-if)# vlan 3
CN 4093(config-ip-if)# exit
CN 4093(config)# router rip
CN 4093(config-router-rip)# enable
CN 4093(config-router-rip)# exit
CN 4093# interface ip 2
CN 4093(config-ip-if)# ip rip enable
CN 4093(config-ip-if)# exit
CN 4093# interface ip 3
CN 4093(config-ip-if)# ip rip enable
CN 4093(config-ip-if)# exit
