536 CN4093 Application Guide for N/OS 8.4

Task 1: Configure CN4093 1

1. OnCN40931,configuretheinterfacesforclients(174.14.20.110)andservers

(10.1.1.110).

2. ConfigureVirtualInterfaceRouters.

3. EnableVRRPHotStandby.

4. ConfigureVRRPGroupparameters.SettheVRRPpriorityto101,sothatthis

switchistheMaster.

5. TurnoffSpanningTreeProtocolglobally..

CN 4093(config)# interface ip 1

CN 4093(config-ip-if)# ip address 174.14.20.110(DefineIPv4addressforinterface1)

CN 4093(config-ip-if)# enable

CN 4093(config-ip-if)# exit

CN 4093(config)# interface ip 2

CN 4093(config-ip-if)# ip address 10.1.1.110(DefineIPv4addressforinterface2)

CN 4093(config-ip-if)# enable

CN 4093(config-ip-if)# exit

CN 4093(config)# router vrrp

CN 4093(config-vrrp)# enable

CN 4093(config-vrrp)# virtual-router 1 virtual-router-id 1

CN 4093(config-vrrp)# virtual-router 1 interface 1

CN 4093(config-vrrp)# virtual-router 1 address 174.14.20.100

CN 4093(config-vrrp)# virtual-router 1 enable

CN 4093(config-vrrp)# virtual-router 2 virtual-router-id 2

CN 4093(config-vrrp)# virtual-router 2 interface 2

CN 4093(config-vrrp)# virtual-router 2 address 10.1.1.100

CN 4093(config-vrrp)# virtual-router 2 enable

CN 4093(config-vrrp)# hot-standby (EnableHotStandby)

CN 4093(config-vrrp)# group enable (EnableVirtualRouterGroup)

CN 4093(config-vrrp)# group virtual-router-id 1(SetVirtualRouterIDforGroup)

CN 4093(config-vrrp)# group interface 1(SetinterfaceforGroup)

CN 4093(config-vrrp)#

group priority 101(SetVRRPpriorityto101)

CN 4093(config-vrrp)# group track ports(Enabletrackingonports)

CN 4093(config)# no spanning-tree stp 1
