534 CN4093 Application Guide for N/OS 8.4
3. TurnonVR RPandconfiguretwoVirtualInterfaceRouters.
4. Enabletrackingonports.SetthepriorityofVirtualRouter2to101,sothatit
becomestheMaster.
5. Configureports.
6. TurnoffSpanningTreeProtocolglobally.
CN 4093(config)# router vrrp
CN 4093(config-vrrp)# enable
CN 4093(config-vrrp)# virtual-router 1 virtual-router-id 1
CN 4093(config-vrrp)# virtual-router 1 interface 1
CN 4093(config-vrrp)# virtual-router 1 address 192.168.1.200
CN 4093(config-vrrp)# virtual-router 1 enable
CN 4093(config-vrrp)# virtual-router 2 virtual-router-id 2
CN 4093(config-vrrp)# virtual-router 2 interface 2
CN 4093(config-vrrp)# virtual-router 2 address 192.168.2.200
CN 4093(config-vrrp)# virtual-router 2 enable
CN 4093(config-vrrp)# virtual-router 1 track ports
CN 4093(config-vrrp)# virtual-router 2 track ports
CN 4093(config-vrrp)# virtual-router 2 priority 101
CN 4093(config-vrrp)# exit
CN 4093(config)# vlan 10
CN 4093(config-vlan)# exit
CN 4093(config)# interface port EXT1
CN 4093(config-if)# switchport mode trunk
CN 4093(config-if)# switchport trunk allowed vlan add 10
CN 4093(config-if)# exit
CN 4093(config)# vlan 20
CN 4093(config-vlan)# exit
CN 4093(config)# interface port EXT2
CN 4093(config-if)# switchport mode trunk
CN 4093(config-if)# switchport trunk allowed vlan add 20
CN 4093(config-if)# exit
CN 4093(config)# no spanning-tree stp 1
