Thefollowingillustrationshowstherearviewoftheserverwithascrew-secured,non-hot-swappowersupply.
Figure6.Rearviewoftheserverwithanon-hot-swappowersupply
1Powercordconnector5Expansioncardarea
2Serialport6Ethernetconnector1(RJ-45)
3VGADB-15connector7Ethernetconnector2(RJ-45)(forsystemmanagement)
4FourUSBconnectors
8Frontdoorkey
20ThinkServerUserGuide
