Thefollowingillustrationshowsthecomponentsoftheserverwithvetoeight3.5-inchhot-swaphard
diskdrives.
Figure11.Componentsoftheserverwithvetoeight3.5-inchhot-swapharddiskdrives
1DITmodule(availableinsomemodels)
12Harddiskdrivebay0
2Frontpanel
13Frontsystemfan1
3Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
14Frontsystemfan2
4Opticaldrivebay1(withanopticaldriveinstalled)15Systemboardbattery
5Harddiskdrivebay716Expansioncard
6Harddiskdrivebay6
17Heatsinkandfanassembly
7Harddiskdrivebay5
18Systemboard
8Harddiskdrivebay4
19Rearsystemfan
9Harddiskdrivebay320Powersupply
10Harddiskdrivebay2
21Fourmemoryslots(installedmemorymodulesvaryby
model)
11Harddiskdrivebay1
•Formoreinformationabout1to4,see“Frontviewoftheserver”onpage15.
Note:TheDITmodule1isonlyavailableinsomemodelsandtheDITpanelalsovariesbymodel.
See“DITmodule”onpage18
.
