Note:Thenumberoftheinstalledharddiskdrivesvariesbymodel.Forthevacantdrivebay,thereisa
dummyharddiskdrivetraytocovertheplace.
•Forinformationaboutthesupportedexpansioncard,see“Systemboardcomponents”onpage42.
•Dependingonthemodel,yourservermightcomewithascrew-secured,non-hot-swappowersupply
orhot-swapredundantpowersupplymodule(s).
•Formoreinformationaboutthememorymodules,see“Memorymoduleinstallationrules”onpage90.
Thefollowingillustrationshowsthecomponentsoftheserverwithuptofour3.5-inchhot-swapharddisk
drives.
Figure13.Componentsoftheserverwithuptofour3.5-inchhot-swapharddiskdrives
1DITmodule(availableinsomemodels)
9Frontsystemfan1
2Frontpanel
10Systemboardbattery
3Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
11Expansioncard(variesbymodel)
4Opticaldrivebay1(withanopticaldriveinstalled)
12Heatsinkandfanassembly
5Harddiskdrivebay3
13Systemboard
6Harddiskdrivebay2
14Rearsystemfan
7Harddiskdrivebay115Powersupply
8Harddiskdrivebay0
16Fourmemoryslots(installedmemorymodulesvaryby
model)
•Formoreinformationabout1to4,see“Frontviewoftheserver”onpage15.
