Commissioning
Setting the IP configuration
42
Lenze · E84AYCER communication module (PROFINET) · EDS84AYCER EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Decimal representation of the IP parameters
By clicking the [int] buttons on the right next to the input fields, the IP parameters are represented
as decimal values.
In the case of the decimal representation, the byte sequence is inverted.
Example: IP address 192.168.0.1
• C13000
= 16820416 [00000001.00000000.10101000.11000000
bin
]
IP address
• Valid IP addresses are defined in accordance with RFC 3330.
• The IP address is set/changed in C13000
.
•In C13010/1...4
the IP address currently used is shown.
Subnet Mask
• The subnet mask indicates which part of the IP address is evaluated as net ID or host ID.
• Valid subnet masks are defined in accordance with RFC 1878
• The subnet mask is set/changed in C13001
.
•In C13011/1...4
the subnet mask currently used is shown.
Gateway address
• The gateway address is valid if the network address of the IP address and the gateway address
are identical.
• If the gateway address and the IP address are identical, gateway functionality is not used.
• DHCP is not supported.
• The gateway address is set/changed in C13002
.
•In C13012/1...4
the gateway address currently used is shown.
Byte 3 Byte 2 Byte 1 Byte 0
1 0 168 192
0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 1 0 1 0 1 0 0 0 1 1 0 0 0 0 0 0
C13010/4 C13010/3 C13010/2 C13010/1
Example: Display of the IP address 192.168.0.1
Code C13010/1
C13010/2 C13010/3 C13010/4
Value 192 168 0 1
Example: Display of the subnet mask 255.255.255.0
Code C13011/1 C13011/2 C13011/3 C13011/4
Value 255 255 255 0
Example: Display of the gateway address 192.168.0.1
Code C13012/1
C13012/2 C13012/3 C13012/4
Value 192 168 0 1
