The modular system
7
Mechanical installation
7.2
l
7.2-1
EDSPM-TXXX-3.0-04/2004
7.2 The modular system
Mounting dimensions and other dimensions
01
60 mm
40 mm
27 mm
7.5/15 mm
35 mm
80 mm
90 mm
76 mm
76 mm
76 mm 76 mm
25.4 mm
25.4 mm
110 mm
epm-t053
Fig. 7.2-1 Module dimensions of the modular system
