12.4 Parameterising 2/4xcounter module
12.4.1 Parameter data
The operating mode of the 2/4xcounter (e. g. 2 x 32-bit counter or 4 x 16-bit
counter) can be determined by assigning each channel (counter 0 and counter 1)
a mode via the parameter data.


 Stop!
Depending on the mode set, the terminal assigment of the counter
module changes!I
For the 2/4xcounter two bytes of parameter data are available which are assigned
via SDOs.
Depending on the plug-in station, the counter module is parameterised via the
indices 3001
h
... 3010
h
(max. 4 counter modules). The parameter data are stored
in the subindex 1.
epm-t062
Fig. 12.4-1 Display of the parameter data of 2/4xcounter
The parameter data follow the assignment below:
Byte Assignment Lenze setting
0 Mode, counter 0
Selecting the modes
00
h
1 Mode, counter 1
g
00
h


 Note!
Store changed parameters in the EEPROM via index I2003
h
.The
settings are maintained after switching off the supply voltage.
Counter mode overview
Mode of
Function IN1 IN2 IN3 IN4 IN5 IN6 OUT0 OUT1 Auto
R
l
d
Compare
L
d
[h] [dec]
o
o
Reload
o
p
Load
2 counters 0 1
00
h
0 32-bit counter RES CLK DIR RES CLK DIR • • – –
01
h
1 Encoder 1 edge RES A B RES A B • • – –
03
h
3 Encoder 2 edges RES A B RES A B • • – –
05
h
5 Encoder 4 edges RES A B RES A B • • – –
