Parameterising 2/4xcounter module
Parameter data
12
Parameter setting
12.4
12.4.1
l
12.4-2
EDSPM-TXXX-3.0-04/2004
Mode of Compare
Load
Auto
Reload
OUT1OUT0IN6IN5IN4IN3IN2IN1Function
[h]
Compare
Load
Auto
Reload
OUT1OUT0IN6IN5IN4IN3IN2IN1Function
[dec]
4 counters 0.1 0.2 1.1 1.2
08
h
8 2 × 16-bit counters
(counting direction up/up)
– CLK CLK – CLK CLK – – – –
09
h
9 2 × 16-bit counters
(counting direction down/up)
– CLK CLK – CLK CLK – – – –
0A
h
10 2 × 16-bit counters
(counting direction up/down)
– CLK CLK – CLK CLK – – – –
0B
h
11 2 × 16-bit counters
(counting direction down/down)
– CLK CLK – CLK CLK – – – –
2 counters 0 1
0C
h
12 2 × 32-bit counters
(counting direction up)
RES CLK GATE RES CLK GATE • • – 9
0D
h
13 2 × 32-bit counters
(counting direction down)
RES CLK GATE RES CLK GATE • • – 9
0E
h
14 2 × 32-bit counters
(counting direction up)
RES CLK GATE RES CLK GATE • • 9 9
0F
h
15 2 × 32-bit counters
(counting direction down)
RES CLK GATE RES CLK GATE • • 9 9
1 counter 0/1
10
h
16 Frequency measuring RES CLK START STOP – – • • – 9
11
h
17 Measuring the period RES CLK START STOP – – • • – 9
12
h
18 Frequency measuring
(Counter output on/off)
RES CLK START STOP – – • • – 9
13
h
19 Measuring the period
(Counter output on/off)
RES CLK START STOP – – • • – 9
2 counters 0 1
06
h
6 Measuring the pulse width
(f
ref
50 kHz, counting direction is
selectable)
RES PULSE DIR RES PULSE DIR – – – –
14
h
20 Measuring the pulse width
(f
ref
programmable, c o unting
direction is selectable)
RES PULSE DIR RES PULSE DIR – – – –
15
h
21 Measuring the pulse width
(f
ref
programmable, c o unting
direction: Upwards)
RES PULSE GATE RES PULSE GATE – – – –
16
h
22 Measuring the pulse width
(f
ref
programmable, c o unting
direction: Downwards)
RES PULSE GATE RES PULSE GATE – – – –
2 counters 0 1
17
h
23 2 × 32-bit counters
(counting direction up, ”Set”
function)
RES CLK GATE RES CLK GATE – – – 9
18
h
24 2 × 32-bit counters
(counting direction do wn, ”Set”
function)
RES CLK GATE RES CLK GATE – – – 9
19
h
25 2 × 32-bit counters
(counting direction up, ”Reset”
function)
RES CLK GATE RES CLK GATE – – – 9
1A
h
26 2 × 32-bit counters
(counting direction down, ”Reset”
function)
RES CLK GATE RES CLK GATE – – – 9
