Parameterising 2/4xcounter module
Parameter data
12
Parameter setting
12.4
12.4.1
l
12.4-3
EDSPM-TXXX-3.0-04/2004
Mode of Compare
Load
Auto
Reload
OUT1OUT0IN6IN5IN4IN3IN2IN1Function
[h]
Compare
Load
Auto
Reload
OUT1OUT0IN6IN5IN4IN3IN2IN1Function
[dec]
2 counters 0 1
1B
h
27 32-bit counter G/RES CLK DIR G/RES CLK DIR • • – –
1C
h
28 Encoder 1 edge G/RES A B G/RES A B • • – –
1D
h
29 Encoder 2 edges G/RES A B G/RES A B • • – –
1E
h
30 Encoder 4 edges G/RES A B G/RES A B • • – –
2 counters 0 1
1F
h
31 2 × 32-bit counters
(counting direction up)
RES CLK GATE RES CLK GATE • • – 9
20
h
32 2 × 32-bit counters
(counting direction down)
RES CLK GATE RES CLK GATE • • – 9
21
h
33 2 × 32-bit counters
(counting direction up)
RES CLK GATE RES CLK GATE • • 9 9
22
h
34 2 × 32-bit counters
(counting direction down)
RES CLK GATE RES CLK GATE • • 9 9
2 counters 0 1
23
h
35 32-bit counter GATE CLK DIR GATE CLK DIR • • – –
24
h
36 Encoder 1 edge GATE A B GATE A B • • – –
25
h
37 Encoder 2 edges GATE A B GATE A B • • – –
26
h
38 Encoder 4 edges GATE A B GATE A B • • – –
• Digital output can signal an event
9 Function available.
– No function / function not available
A Encoder signal A
Auto Reload ”Auto Reload” causes the counter to accept a preset value as soon
as the counter content matches the Compare register content.
B Encoder signal B
Compare Load You may use ”Compare Load” to specify a counter limit value to
trigger an output when reached or to restart the counters via Auto
Reload.
CLK Clock signal of a connected encoder
HIGH level starts and / or stops the counting process
DIR Indicates counting direction depending on signal level
LOW: Upcounter
HIGH: Downcounter
GATE Gate signal is level-triggered
HIGH: Pulses are measured
G/RES Gate signal is level-triggered and reset signal is edge-triggered
HIGH: Pulses are measured
LOW-HIGH edge: Deletes one or both counters
PULSE The pulse width of the supplied signal is measured with an internal
time base
RES Reset signal is level-triggered
HIGH: Deletes one or both counters
RES Reset signal is edge-triggered
LOW-HIGH edge: Deletes one or both counters
START Start signal is edge-triggered
STOP Stop signal is edge-triggered
